ZKTeco · Standalone Fingerprint
MK-V1
MK-V1
MK-V1 is a ZKTeco standalone fingerprint product in the Access Controllers range. The available official record includes Model, Operation System and Hardware.
- Standalone Fingerprint
- ZKTeco
- 21 listed specifications
About this product
MK-V1 overview
MK-V1 appears in ZKTeco India's Standalone Fingerprint section within the Access Controllers product range. This Minal Infotek record keeps the model, product image and available technical fields together for enquiry preparation.
The specification table below reflects the fields available on the official product page when checked on 2026-07-23. Confirm final door capacity, reader compatibility, network requirements and availability with Minal Infotek before ordering.
- Product group
- Access Controllers
- Subcategory
- Standalone Fingerprint
- Brand
- ZKTeco
- Recorded model
- MK-V1
- Verified fields
- 21
Product record
Specifications
- Model
- MK-V1
- Operation System
- Linux
- Hardware
- CPU: CKSF030 RAM: 8KB; ROM: 64KB Touch Keypad: 12 Keys
- Password Capacity
- 6 Digits
- Card Reading Distance
- 2cm to 6cm
- Authentication Method
- Card / Password
- Card Type
- ID & IC (125 kHz & 13.56 MHz Dual Frequency)
- Certifications
- ISO9001, ISO14001, CE, RoHS, FCC
- Communication
- Wi-Fi (IEEE802.11n/b/g) @ 2.4 GHz Bluetooth: BLE5.0 Wiegand (Input & Output)*1 Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1
- Dimensions(L*W*D)
- 165 mm*44 mm*22 mm (L*W*H)
- Gross Weight
- 0.500 Kg
- ID Card Capacity
- 888 (1:N) (Standard )
- IP Rating
- IP66 (waterproof and dustproof )
- Installation Method
- Wall-mount
- Net Weight
- 0.415 Kg
- Operating Humidity
- 0% to 98% RH (Non-condensing)
- Operating Temperature
- -20°C to 60°C
- Power Supply
- DC 12-18V
- Standard Functions
- Access Control, Buzzer, LED (Green: verification successful ; Red: Normal Status ; Blue: verification is in process), Multiple Verification Methods
- Supported Software
- Mobile App: ZSmart (Mobile Credential)
- Transaction Capacity
- 1,000(Standard )
Specifications and product image sourced from the official ZKTeco India product page. Please confirm current availability before ordering.
